| Electrical performance parameters | |
| GPS part: | |
| Frequency | 1575.42MHz |
| Gain | 28±2dB Typical |
| V.S.W.R | ＜2.0 |
| Polarization | RHCP |
| Radiative properties | Omni |
| Input maximum power | 50W |
| Impendance | 50Ώ |
| Noise figure | 1.5dB |
| Prime power | 2.2-5.0V |
| Operating current | 5-15mA |
| LTE Part: | |
| Frequency | 698-960/1710-2700MHz |
| V.S.W.R | ＜2.0 |
| Gain | 3dBi |
| Polarization | Linear |
| Impendance | 50Ω |
| WIFI Part: | |
| Frequency | 2.4/5GHZ |
| V.S.W.R | ＜2.5 |
| Gain | 3dBi |
| Polarization | Linear |
| Impendance | 50Ω |
| Electrical performance parameters | |
| Shell | Black |
| Product Material | ABS |
| feeder | 1M(RG174)*3 |
| Connector | 3xMMCX |
| working temperature | -40°C~+80°C |
| humidity | 55%-75%RH |
| Waterproof grade | IP67 |
| humidity | 95%~100%RH |
